Compression Testing Equipment Manually Hand Operated Manufacturer,Supplier and Exporter in China
Product Code : EL-CTLE-11203
These strength testing equipment are extremely handy Edulab China and are easy to use for testing cement, concrete and mortar cubes.
We lay utmost importance on equipment design and construct with emphasis on ease of operation.
Compressive Strength Testing Equipment to test cement, brick and concrete is offered by us. The range we offer includes Manually (Hand) Operated, Semi Automatic Compression Testing Equipment, Electrically Cum Manually Operated equipment and more.
Compression Testing Equipment Manually (Hand) Operated fitted with single load gauge.
The loads are measured on Bourdon tube type load gauges which are calibrated against certified proving rings.
The load gauges are fitted with a maximum load pointer.
Specifications:
Pressure Gauge Diameter (mm): 150
Vertical Daylight (mm): 320 (Adj)
Capacity (In kN): 1000 kN
Pressure Gauge (In kN): 1000 kN
Least Count (In kN): 5 kN
Brand: Edulab China
Ram Travel (mm): 50
Cube: 100mm, 150 mm
Cylindrical: 100 mm x 200 mm, 150 mm x 300 mm
Brick: 100 x 100 x 220 mm
Horizontal Clearance (mm): 260
Platen Size (mm): 220 x 165
Ram Diameter (mm): 165
