Automatic Digital Compression Testing Machine

Product Code : EL-CTLE-11208

Edu Lab China is a leading Automatic Digital Compression Testing Machine Manufacturer,and suppliers in China, Automatic Digital Compression Testing Machine Manufacturer,and suppliers in China, Automatic Digital Compression Testing Machine Algeria (Algiers), Automatic Digital Compression Testing Machine Angola (Luanda), Automatic Digital Compression Testing Machine Argentina (Buenos Aires), Automatic Digital Compression Testing Machine Armenia (Yerevan), Automatic Digital Compression Testing Machine Australia (Canberra), Automatic Digital Compression Testing Machine Austria (Vienna), Bahrain (Manama), Bangladesh (Dhaka), Bhutan (Thimphu), Bolivia (Sucre), Botswana (Gaborone), Brazil (Brasília), Brunei (Bandar Seri Begawan), Montenegro (Podgorica), Morocco (Rabat), Mozambique (Maputo), Myanmar (Naypyidaw), Namibia (Windhoek), Nepal (Kathmandu), New Zealand (Wellington), Nigeria (Abuja), Oman (Muscat), Palestine (Ramallah), Panama (Panama City), Papua New Guinea (Port Moresby), Paraguay (Asunción), Peru (Lima), Philippines (Manila)¸ Portugal (Lisbon), Qatar (Doha), Rwanda (Kigali), Saudi Arabia (Riyadh), Senegal (Dakar), Serbia (Belgrade), Sierra Leone (Freetown), Slovakia (Bratislava), South Africa (Cape Town) (Pretoria) (Bloemfontein), South Sudan (Juba), Spain (Madrid), Sri Lanka (Sri Jayawardenepura Kotte) (Colombo), Sudan (Khartoum), Syria (Damascus), Tanzania (Dodoma), Thailand (Bangkok), Togo (Lomé), Tonga (Nuku'alofa), Trinidad and Tobago (Port of Spain), Tunisia (Tunis), Turkey (Ankara), Turkmenistan (Ashgabat), Uganda (Kampala), United Arab Emirates (Abu Dhabi), United Kingdom (London), United States (Washington, D.C.).

The automatic range of 3000 kn capacity Automatic digital compression testing machine has been designed to meet the need for reliable and consistent testing of concrete samples all Edulab China machines feature the complete automatic test cycle with a closed loop digital readout.
Once the specimen parameters have been introduced, it is sufficient to press the start button to complete the test.
Automatic digital compression testing machine consist of their main parts: frame, power pack and data acquisition & control system.

Menu driven software for easy operation
Load vs time plot and instantaneous load rate displayed
Automatic test cycle with standard rapid approach
Class 1 starting from % 10 of the full range
Metric, Imperial units
Data storage up to 256 tests
RS 232 output for printer or PC
Graphical – LCD data acquisition and control system
Accurate load rate control within ±5 from 1 kN/sec to 20 kN /sec

Specifications:


Model

EDS1

EDS2

Capacity

2000kN

3000 kN

Standard

EN

EN

The roughness value for texture of loading and auxiliary platens

≤ 3.2 µm

≤ 3.2 µm

Lower platens dimensions (dia.)

300 mm

300 mm

Upper platens dimensions (dia.)

300 mm

300 mm

Maximum vertical clearance between platens

340 mm

340 mm

Piston diameter

250 mm

300 mm

Maximum piston movement

50 mm

50 mm

Horizontal clearance

360 mm

425 mm

Power

750 W

750 W

Oil capacity

20 L

20 L

Maximum working pressure

410 Bar

410 Bar

Dimensions (W x L x H) (mm)

810 x 500 x 970

810 x 500 x 970

Weight

795 kg

1095 kg
